Martin 80BTB12 Bushing Bore Roller Chain Sprocket - Taper Locking, 80 / 1 in, 12 Teeth, 1615 Bushing

Product Description

The Martin 80BTB12 bushing bore roller chain sprocket is a reliable component for mechanical power transmission systems. It features a taper locking mechanism ensuring a strong grip on the shaft for effective power transfer. With twelve teeth and a pitch of 80 / 1 inch, this sprocket fits into various chain applications. It can accommodate bushings ranging from one-half inch to one and five-eighths inches. This sprocket is manufactured from high-carbon steel, ensuring durability and consistent performance.

• Taper locking bushing for secure fit
• Meets ANSI standards for quality and performance
• Compatible with standard roller chains

Product Highlights

This sprocket features a tapered bushing bolted into a taper bore, which provides a tight and reliable connection to the chain. Its design ensures precise alignment and minimizes runout, extending the life of both the sprocket and the chain. This component is ideal for various industrial applications, often used in conjunction with conveyor systems and other machinery that relies on roller chain mechanisms.

Product Information

Standard Information

• Brand: Martin
• Country Of Origin: United States

Technical Specifications

• Pitch Type: Single
• Tooth Width: 0.575 inches
• Hub Diameter: 3 inches
• Overall Width: 1.5 inches
• Pitch Diameter: 3.8637 inches
• Number Of Teeth: 12
• Outside Diameter: 4.3320 inches
• Surface Treatment: Protective Coating
• Bushing Bore Range: 0.5 to 1.625 inches
• Length Through Bore: 1.5000 inches
• Chain Number & Pitch: 80 / 1 inches
• Manufacturer UPC Number: 697950032139
