Martin 80BS16HT1 SABER Finished Bore Sprocket - Bored to Size, 1.0000 in Bore, 16 Teeth, Steel Material

Product Description

The Martin 80BS16HT1 SABER Finished Bore Sprocket is a robust mechanical component made from high carbon steel. This sprocket features a boring size of one inch and has sixteen teeth, making it suitable for various applications within roller chain systems.

• Finished bore design for precise compatibility with shafts.
• Comes with keyways and setscrews for secure attachment.
• Manufactured to meet or exceed ANSI standards for quality assurance.

Product Highlights

This finished bore sprocket is designed for durability and reliability in mechanical power transmission tasks.

Product Information

Standard Information

• Brand: Martin
• Country Of Origin: United States

Technical Specifications

• Material: Steel
• Bore Diameter: 1.0000 in
• Number Of Teeth: 16
• Tooth Width: 0.5750 in
• Pitch Diameter: 5.1258 in
• Hub Diameter: 4 in
• Outside Diameter: 5.6270 in
• Hub Projection: 0.9219 in
• Set Screw Size: .313-18 X .313 in
• Hardened Teeth: With Hardened Teeth
• Maximum Bore Diameter: 2.75 in
• Number Of Set Screws: 2
