Martin 60P25H Bushing Bore Roller Chain Sprocket - Split Taper, 60 / 3/4 in, 25 Teeth, P1 Bushing, Steel Material

Product Description

The Martin 60P25H is a bushing bore roller chain sprocket designed for durability and efficiency. This split taper sprocket features a bore range from one half inches to one and three quarter inches. It is suitable for a variety of mechanical applications.

• Split taper bushing allows for a wide range of bore sizes.
• Manufactured from high carbon steel for strength and resilience.
• Compatible with other manufacturers’ split-taper bushings.

Product Highlights

This sprocket is designed to meet or exceed ANSI standards, ensuring reliability and long life in daily use.

Product Information

Standard Information

• Brand: Martin
• Manufacturer Catalog No: 00540

Technical Specifications

• Weight: 4.19 lbs
• Material: Steel
• Bore Type: Bushed
• Chain Number: 60
• Tooth Width: 0.459 in
• Bushing Size: P1
• Number Of Teeth: 25
• Pitch Diameter: 5.9840 in
• Outside Diameter: 6.3870 in
• Length Through Bore: 1.3125 in
• Hub Diameter: 3 in
• Overall Width: 2-3/16 in
• Caliper Diameter: 5.5032 in
• Storage Dimension Width: 6.3870 in
• Storage Dimension Height: 1.3125 in
• Storage Dimension Length: 6.3870 in
• Surface Treatment: Protective Coating
• Number Of Hubs: 1
