Martin 60H24H Bushing Bore Roller Chain Sprocket - Split Taper, 60 / 3/4 in, 24 Teeth, H Bushing

Product Description

The Martin 60H24H is a bushing bore roller chain sprocket featuring a split taper design. This sprocket includes twenty-four teeth and is manufactured with high carbon steel for improved durability. It is compatible with a wide range of bore sizes due to its interchangeable split taper bushing. This sprocket is designed to align with the pitch line, which minimizes run out for consistent performance.

• Constructed from high carbon steel
• Meets ANSI standards for tolerances
• Compatible with a range of manufacturers' split taper bushings

Product Highlights

This sprocket is ideal for mechanical power transmission applications where reliability and precision are crucial.

Product Information

Standard Information

• Country Of Origin: United States
• Availability Remarks: Factory Order

Technical Specifications

• Weight: 3.33 lbs
• Material: Steel
• Bore Type: Bushed
• Pitch Type: Single
• Tooth Width: 0.459 in
• Bushing Size: H
• Bushing Type: Split Taper Bushing
• Chain Number: 60
• Hub Diameter: 2-1/2 in
• Overall Width: 1-1/2 in
• Number Of Hubs: 1
• Pitch Diameter: 5.7460 in
• Number Of Teeth: 24
• Outside Diameter: 6.1470 in
• Bushing Bore Range: 3/8 to 1-1/2 in
• Length Through Bore: 0.8750 in
• Chain Number & Pitch: 60 / 3/4 in
• Manufacturer UPC Number: 697950138114
• Storage Dimension Width: 6.1470 in
• Storage Dimension Height: 0.8750 in
• Storage Dimension Length: 6.1470 in
