Martin 60BTB24H Saber Tooth Taper Bushed Type B Roller Chain Sprocket

Product Description

The Martin Saber Tooth® 60BTB24H is a taper bushed type B single pitch roller chain sprocket. This sprocket is designed for use with #60 chain and features twenty-four teeth. The outside diameter is six point one four seven inches, and it has a pitch of three-quarters of an inch.

• Manufactured from high carbon steel for durability
• Tapered bushing provides a secure fit on the shaft
• Compatible with a variety of machinery for effective power transmission

Product Highlights

This product allows for reliable performance in various applications with a hard-wearing construction.

Product Information

Standard Information

• Brand: Martin
• Manufacturer: Martin Sprocket & Gear

Technical Specifications

• MPN: 60BTB24H
• Chain Size: #60
• Number of Teeth: 24
• Outside Diameter: 6.147 inches
• Pitch Diameter: 5.746 inches
• Hub Diameter: 3.563 inches
• Length Through Bore: 1-1/4 inches
• Bushing Type: 2012 Taper Lock
• Material: Steel
• Pitch: 3/4 inches
