Martin 60BTB23 Bushing Bore Roller Chain Sprocket - Taper Locking, 60 / 3/4 in, 23 Teeth, 2012 Bushing, Steel Material

Product Description

The Martin 60BTB23 is a taper locking bushing bore roller chain sprocket designed for use with standard roller chains. It has twenty-three teeth and features a bore range from half inch to two inches. This sprocket is manufactured from high carbon steel, ensuring durability and reliability in mechanical power transmission tasks.

• Taper locking design for secure fitting
• Compatible with standard roller chains of pitch sixty / three-fourth inch
• Manufactured to meet ANSI standards for quality

Product Highlights

The Martin 60BTB23 sprocket is ideal for heavy-duty applications where chain stability and longevity are required. Its precise machining allows for seamless integration with compatible shafts, enhancing overall performance.

Product Information

Standard Information

• Brand: Martin
• Country Of Origin: United States

Technical Specifications

• Manufacturer Part Number: 60BTB23
• Number Of Teeth: 23
• Chain Number & Pitch: 60 / 3/4 in
• Pitch Diameter: 5.5080 in
• Hub Diameter: 4 in
• Overall Width: 1-1/4 in
• Outside Diameter: 5.9070 in
• Length Through Bore: 1.2500 in
• Surface Treatment: Protective Coating
