Martin 60BS482 Bored to Size Sprocket - 60 / 3/4 in

Product Description

The Martin 60BS482 is a bored to size sprocket designed for versatility in mechanical power transmission. This sprocket features a bore size of two inches and forty-eight teeth, making it suitable for a variety of applications. The product is made from high carbon steel and is manufactured in the United States.

• Finished bore with keyways and setscrews included
• Tolerances meet or exceed ANSI standards
• Meets high quality requirements through precise machining processes

Product Highlights

The Martin 60BS482 sprocket is shaft ready and comes with features like concentric bores to minimize run out, ensuring smooth operation in your mechanical systems.

Product Information

Standard Information

• Brand: Martin
• Country Of Origin: United States

Technical Specifications

• Weight: 14.13 lbs
• Material: Steel
• Bore Type: Bored to Size
• Pitch Type: Single
• Bore Diameter: 2.0000 in
• Keyway Size: 1/2 x 1/4 in
• Tooth Width: 0.459 in
• Hub Diameter: 4-1/4 in
• Number Of Teeth: 48
• Outside Diameter: 11.8930 in
• Length Through Bore: 1.2500 in
• Chain Number & Pitch: 60 / 3/4 in
• Manufacturer UPC Number: 697950308722
