Martin 60BS1813/16 Bored to Size Sprocket - 60 / 3/4 in

Product Description

The Martin 60BS1813/16 is a bored to size sprocket designed for compatibility with standard roller chains. This component features an inner bore of 1.1875 inches and has 18 teeth. It is made from steel for durability and reliability in mechanical power transmission tasks.

• Constructed from high carbon steel.
• Precision bored and keyed for optimal performance.
• Manufactured to meet ANSI tolerances.

Product Highlights

This sprocket is ready for use with setscrews included for secure installation. The keyways are on the center line of the tooth for accurate alignment.

Product Information

Standard Information

• Brand: Martin
• Country of Origin: United States

Technical Specifications

• Pitch Type: Single
• Tooth Width: 0.459 inches
• Hub Diameter: 3-1/2 inches
• Bore Diameter: 1.1875 inches
• Hardened Teeth: Non-Hardened
• Number of Hubs: 1
• Pitch Diameter: 4.3191 inches
• Number of Teeth: 18
• Caliper Diameter: 3.8501 inches
• Outside Diameter: 4.7030 inches
• Surface Treatment: Protective Coating
• Length Through Bore: 1.2500 inches
• Chain Number & Pitch: 60 / 3/4 in
• Chain / Sprocket Type: Standard Roller Chain
• Manufacturer UPC Number: 697950016214
• Storage Dimension Width: 4.8125 inches
• Number Of Strands Across: 1
• Storage Dimension Height: 1.3125 inches
• Storage Dimension Length: 4.8125 inches
