Martin 50BTB40 Bushing Bore Roller Chain Sprocket - Taper Locking, 50 / 5/8 in, 40 Teeth, 2012 Bushing

Product Description

The Martin 50BTB40 is a bushing bore roller chain sprocket that features taper locking technology. This product is designed with 40 teeth and fits a chain pitch of 50 / 5/8 inches. Made of high carbon steel, it ensures durability and reliability in various mechanical applications.

• Features a taper-bushed design for a secure fit on the shaft.
• Manufactured to meet ANSI standards for precision and quality.
• Compatible with other manufacturers’ taper bushings.

Product Highlights

This sprocket excels in machinery that requires reliable power transmission. Its construction allows for high performance and longevity.

Product Information

Standard Information

• Brand: Martin
• Country Of Origin: United States

Technical Specifications

• Pitch Type: Single
• Number Of Teeth: 40
• Chain Number & Pitch: 50 / 5/8 in
• Hub Diameter: 3-9/16 inches
• Overall Width: 1-1/4 inches
• Outside Diameter: 8.3160 inches
• Length Through Bore: 1.2500 inches
• Bushing Bore Range: 1/2 to 2 inches
• Surface Treatment: Protective Coating
• Manufacturer UPC Number: 697950031293
