Martin 50BTB32 Bushing Bore Roller Chain Sprocket - Taper Locking 50 / 5/8 in 32 Teeth 2012 Bushing

Product Description

The Martin 50BTB32 Bushing Bore Roller Chain Sprocket is designed for standard roller chain applications. This sprocket features a taper locking mechanism that ensures a secure fit on the shaft. It includes a bushing that is compressed during installation, providing a tight grip. The product falls within the mechanical power transmission category, specifically designed for those using chain and sprocket systems.

• Manufactured from high carbon steel for durability
• Meets or exceeds ANSI standards for performance
• Precision machined for a high-quality finish

Product Highlights

Suitable for a variety of applications. Features a protective coating for extended life. Sprocket is compatible with other manufacturers’ taper bushings.

Product Information

Standard Information

• Country of Origin: United States
• Minimum Order Quantity: 1

Technical Specifications

• Pitch Type: Single
• Number of Teeth: 32
• Pitch Diameter: 6.3764 in
• Hub Diameter: 3-9/16 in
• Tooth Width: 0.343 in
• Overall Width: 1-1/4 in
• Outside Diameter: 6.7210 in
• Caliper Diameter: 5.9764 in
• Bushing Bore Range: 1/2 to 2 in
• Length Through Bore: 1.2500 in
• Chain Number & Pitch: 50 / 5/8 in
• Storage Dimension Width: 6.721 in
• Storage Dimension Height: 1.25 in
• Storage Dimension Length: 6.721 in
