Martin 50BTB19 Bushing Bore Roller Chain Sprocket - Taper Locking, 50 / 5/8 in, 19 Teeth, 1610 Bushing, Steel Material

Product Description

The Martin 50BTB19 is a taper locking bushing bore roller chain sprocket made for standard roller chains. It features a bore size of five-eighths inches and has a total of nineteen teeth. This sprocket is built from high carbon steel ensuring durability and reliability under various mechanical conditions.

• Bushing range from half inch to one and five-eighths inch.
• Designed for ANSI standards for precision.
• Sprocket dimensions ensure a tight fit with minimized run out.

Product Highlights

This sprocket provides a secure fit with its tapered bushing design, which is bolted into place. The precise machining enhances performance and longevity while maintaining consistent chain alignment.

Product Information

Standard Information

• Brand: Martin
• Country of Origin: United States

Technical Specifications

• Pitch Type: Single
• Hub Diameter: 3 inches
• Overall Width: 1 inch
• Pitch Diameter: 3.7972 inches
• Outside Diameter: 4.1200 inches
• Length Through Bore: 1 inch
• Chain Number & Pitch: 50 / 5/8 inches
• Number of Teeth: 19
