Martin 50BTB17H Bushing Bore Roller Chain Sprocket - Taper Locking, 50 / 5/8 in, 17 Teeth, 1610 Bushing, Steel Material

Product Description

The Martin 50BTB17H is a bushing bore roller chain sprocket designed for durability and efficiency. With a taper locking mechanism, this sprocket provides a secure grip on the shaft, minimizing slip during operation. Ideal for use in various mechanical power transmission applications, it features a robust steel construction that ensures longevity.

• Designed for single pitch roller chains
• Made from high carbon steel for added strength
• Features a protective coating for improved durability

Product Highlights

Efficient design reduces wear on both sprocket and chain, enhancing overall system performance.

Product Information

Standard Information

• Brand: Martin
• Country of Origin: United States

Technical Specifications

• Pitch Type: Single
• Hub Diameter: 2-25/32 inches
• Number of Teeth: 17
• Pitch Diameter: 3.4014 inches
• Chain Roller Width: 0.3750 inches
• Tooth Width: 1 inch
• Overall Width: 1 inch
• Outside Diameter: 3.7180 inches
