Martin 50BTB14 Bushing Bore Roller Chain Sprocket - Taper Locking, 50 / 5/8 in, 14 Teeth, 1008 Bushing, Steel Material

Product Description

The Martin 50BTB14 Bushing Bore Roller Chain Sprocket features a taper locking mechanism designed for durability and efficiency. This sprocket is suitable for use with standard roller chains of size 50 and 5/8 inches, and it has a total of 14 teeth. It is constructed from steel, making it robust enough to handle various mechanical loads.

• Compatible with 50 / 5/8 in roller chain
• Taper bushings provide secure fitting on shaft
• Manufactured from high carbon steel

Product Highlights

This sprocket is designed for effective power transmission in mechanical systems. The taper bushed design allows for an easy installation while ensuring a secure grip on the shaft.

Product Information

Standard Information

• Brand: Martin
• Country Of Origin: United States

Technical Specifications

• MPN: 50BTB14
• Number Of Teeth: 14
• Pitch Diameter: 2.8087 in
• Overall Width: 7/8 in
• Hub Diameter: 1-15/16 in
• Length Through Bore: 0.8750 in
• Bushing Bore Range: 1/2 to 1 in
• Chain Number & Pitch: 50 / 5/8 in
• Surface Treatment: Protective Coating
