Product Description
The Martin 50BS5413/16 is a bored to size sprocket designed for high efficiency in power transmission systems. This sprocket features a bore diameter of one point one eight seven five inches and has fifty-four teeth. It is crafted from steel material for durability and strength.
- Finished bore with keyways and setscrews included
- Meets or exceeds ANSI standards for quality
- Concentricly bored to minimize run out
Product Highlights
This finished bore sprocket is suitable for use with standard roller chains. Its design ensures reliable operation in mechanical power transmission applications.
Product Information
Standard Information
-
Brand: Martin
-
Country Of Origin: United States
Technical Specifications
-
MPN: 50BS5413/16
-
Material: Steel
-
Bore Type: Bored to Size
-
Pitch Type: Single
-
Bore Diameter: 1.1875 in
-
Keyway Size: 1/4 x 1/8 in
-
Tooth Width: 0.343 in
-
Hub Diameter: 3-3/4 in
-
Number Of Teeth: 54
-
Outside Diameter: 11.1060 in
-
Length Through Bore: 1.2500 in
-
Chain Number & Pitch: 50 / 5/8 in
-
Surface Treatment: Protective Coating
