Martin 50BS283/4 Bored to Size Sprocket - 5/8 in - 28 Teeth

Product Description

The Martin 50BS283/4 is a bored to size sprocket designed for use in mechanical power transmission systems. This sprocket features a bore size of zero point seven five inches and has twenty-eight teeth. Made from high carbon steel, it is designed for durability and efficiency in applications requiring precise transmission of mechanical power.

• Finished bore with keyways and setscrews
• Manufactured in the United States
• Tolerances meet ANSI standards

Product Highlights

This sprocket is shaft ready, with keyways positioned on the center line of the tooth, ensuring reliable performance.

Product Information

Standard Information

• Brand: Martin
• Country Of Origin: United States

Technical Specifications

• MPN: 50BS283/4
• Bore Diameter: 0.7500 inches
• Teeth Count: 28
• Material: Steel
• Pitch Diameter: 5.5821 inches
• Outside Diameter: 5.9220 inches
• Hub Diameter: 3 inches
• Length Through Bore: 1.2500 inches
• Number Of Hubs: 1
• Surface Treatment: Protective Coating
• Chain Number & Pitch: 50 / 5/8 inches
• Keyway Size: 3/16 x 3/32 inches
