Martin 50BS261 Bored to Size Sprocket - 50 / 5/8 in

Product Description

The Martin 50BS261 is a bored-to-size sprocket designed for use in mechanical power transmission applications. This component features a bore diameter of one inch and has twenty-six teeth, suitable for a chain size of fifty or five-eighths inches. Made from high carbon steel, this sprocket is durable and efficiently handles various applications.

• Includes keyways and setscrews for secure installation.
• Concentric bore minimizes run-out issues.
• Manufactured to meet or exceed ANSI standards.

Product Highlights

The 50BS261 sprocket is ready for immediate use with its finished bore and is ideal for standard roller chain systems.

Product Information

Standard Information

• Product Name: Bored to Size Sprocket
• Brand: Martin

Technical Specifications

• Pitch Type: Single
• Tooth Width: 0.343 inches
• Hub Diameter: 3 inches
• Bore Diameter: 1.0000 inches
• Hardened Teeth: Non-Hardened Teeth
• Number Of Hubs: 1
• Pitch Diameter: 5.1851 inches
• Number Of Teeth: 26
• Caliper Diameter: 4.7851 inches
• Outside Diameter: 5.5220 inches
• Surface Treatment: Protective Coating
• Length Through Bore: 1.2500 inches
• Chain Number & Pitch: 50 / 5/8 inches
• Chain / Sprocket Type: Standard Roller Chain
• Manufacturer UPC Number: 697950012322
