Martin 50BS24HT1 Saber Finished Bore Sprocket - Bored to Size, 1.0000 in Bore, 24 Teeth, Steel Material

Product Description

The Martin 50BS24HT1 Saber Finished Bore Sprocket is designed for mechanical power transmission. Its bored size is one inch with twenty-four teeth made from steel. This sprocket is ready for shaft attachment and includes keyways and setscrews for secure fitting.

• Durable construction from high carbon steel
• Manufactured to ANSI standards for precision
• Keyways positioned on the center line of the tooth

Product Highlights

This finished bore sprocket provides enhanced depth and heat treatment to extend the life of the product, making it suitable for various applications in mechanical systems.

Product Information

Standard Information

• Brand: Martin
• Country Of Origin: United States

Technical Specifications

• Bore Diameter: 1.0000 in
• Number Of Teeth: 24
• Outside Diameter: 5.1220 in
• Hub Diameter: 3 in
• Set Screw Size: .313-18 X .313 in
• Length Through Bore: 1.2500 in
• Maximum Bore Diameter: 2 in
• Number Of Set Screws: 2
