Martin 50BS173/4 Bored to Size Sprocket - 50 / 5/8 in

Product Description

The Martin 50BS173/4 is a bored to size sprocket designed for standard roller chain applications. The sprocket features a five-eighth inch bore and has seventeen teeth. It is made of high carbon steel which provides durability and strength.

• Finished bore for direct shaft mounting
• Includes keyways and setscrews for secure attachment
• Manufactured to exceed ANSI standards

Product Highlights

This sprocket is ideal for mechanical power transmission needs, ensuring a precise fit and reliable performance.

Product Information

Standard Information

• Brand: Martin
• Country Of Origin: United States

Technical Specifications

• Bore Diameter: 0.7500 in
• Pitch Diameter: 3.4014 in
• Outside Diameter: 3.7180 in
• Caliper Diameter: 2.9869 in
• Hub Diameter: 2-11/16 in
• Tooth Width: 0.343 in
• Length Through Bore: 1.0000 in
• Number Of Teeth: 17
• Chain Number & Pitch: 50 / 5/8 in
• Number Of Hubs: 1
• Storage Dimension Width: 4.3125 in
• Storage Dimension Height: 1.0625 in
• Storage Dimension Length: 4.3125 in
• Surface Treatment: Protective Coating
• Hardened Teeth: Non-Hardened Teeth
