Martin 50BS167/8 Bored to Size Sprocket - 50 / 5/8 in

Product Description

The Martin 50BS167/8 is a bored-to-size sprocket designed for immediate shaft application. It features a bore diameter of zero point eight seven five inches and a total of sixteen teeth, making it suitable for standard roller chain systems. This sprocket is constructed from high carbon steel for durability and strength.

• Finished bore design for easy installation
• Includes two setscrews and keyways
• Tolerances compliant with ANSI standards

Product Highlights

The Martin 50BS167/8 ensures precise performance with concentric bores minimizing runout. Ideal for various mechanical settings, its protective coating enhances longevity.

Product Information

Standard Information

• Brand: Martin
• Country Of Origin: United States

Technical Specifications

• MPN: 50BS167/8
• Bore Diameter: 0.8750 in
• Number Of Teeth: 16
• Pitch Diameter: 3.2036 in
• Hub Diameter: 2-1/2 in
• Chain Number & Pitch: 50 / 5/8 in
• Tooth Width: 0.343 in
• Outside Diameter: 3.5170 in
• Length Through Bore: 1.0000 in
• Storage Dimension Width: 3.6250 in
• Storage Dimension Height: 1.0625 in
• Storage Dimension Length: 3.6250 in
• Surface Treatment: Protective Coating
• Manufacturer UPC Number: 697950010663
