Martin 40L075SDS L Series, 3/8 Pitch QD Timing Pulley

Product Description

Martin 40L075SDS is a well-engineered timing pulley, designed for reliable belt engagement over a variety of applications. These timing pulleys feature evenly spaced grooves for optimal belt interaction. The design ensures minimal friction during operation, contributing to efficient performance.

• 0.375 inch Belt Pitch
• 0.75 inch Belt Width
• 40 Teeth Count

Product Highlights

Ideal for machinery that requires timed drives such as agitators, pumps, and conveyors.

Product Information

Standard Information

• Brand: Martin
• MPN: 40L075SDS

Technical Specifications

• Hub Type: B
• Number of Teeth: 40
• Outside Diameter: 4.7450 inches
• Type: QD
• Bore Range Max: 2 inches
• Length Through Bore: 1 3/8 inches
• Belt Size: L
• Bushing Series: SDS
• Belt Pitch: 3/8 inch
• Belt Width: 3/4 inch
• Bore Type: Bushed
• Material: Steel
• Bushing Type: Quick Disconnect
• Weight: 1.8 lbs
• EAN or UPC: 697950152196
