Martin 40BTB15H MSG Taper Bushed Type B Single Pitch Roller Chain Sprocket 1008 Taper Lock

Product Description

The Martin 40BTB15H is a taper bushed single pitch roller chain sprocket. It features a hardened design for improved durability and is compatible with #40 chains. The sprocket has 15 teeth and an outside diameter of two point six five two inches. It utilizes a tapered bushing that ensures a secure fit on the shaft, maximizing the lifetime of the sprocket.

• High carbon steel construction
• Compatible with #40 roller chain
• Designed for precision and longevity

Product Highlights

This sprocket is ideal for use in power transmission systems, enhancing efficiency in various mechanical applications.

Product Information

Standard Information

• Brand: Martin
• Part Number: 40BTB15H

Technical Specifications

• Pitch: 1/2 in
• Material: Steel
• Chain Size: #40
• Bushing Type: 1008 Taper Lock
• Hub Diameter: 1.813 in
• Pitch Diameter: 2.405 in
• Number of Teeth: 15
• Outside Diameter: 2.652 in
• Length Through Bore: 7/8 in
• Country of Origin: US
