Martin 40BS9HT5/8 SABER Finished Bore Sprocket - Bored to Size, 0.6250 in Bore, 9 Teeth

Brand: MARTIN
SKU: 40BS9HT5/8
Availability: Out Of Stock
Call for Pricing Call for pricing (215) 326-9845
Call for Pricing Call for pricing (215) 326-9845
HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

The Martin 40BS9HT5/8 is a finished bore sprocket designed for reliable performance. This sprocket features a bore size of 0.6250 inches with nine teeth. Constructed from high carbon steel, it is designed to meet toughness and durability standards.

  • Hardened teeth for increased longevity
  • Keyways positioned on the centerline for easy installation
  • Concentric bore for minimized runout

Product Highlights

This sprocket is suited for various mechanical applications and is ideal for use in chain drive systems.

Product Information

Standard Information

  • Brand: Martin
  • Country of Origin: United States
Technical Specifications
Pitch Type
Single
Tooth Width
0.2840 in
Hub Diameter
1-1/16 in
Bore Diameter
0.6250 in
Hardened Teeth
With Hardened Teeth
Number of Hubs
1
Pitch Diameter
1.4619 in
Set Screw Size
.250-20 X .250 in
Number of Teeth
9
Caliper Diameter
1.1277 in
Hub Recess Depth
0.1095 in
Hub Recess Width
0.1875 in
Outside Diameter
1.6740 in
Set Screw Location
2SS, KEYWAY & 90 degrees
Length Through Bore
0.8750 in
Chain Number & Pitch
40 / 1/2 in
Hub Outside Diameter
1.0625 in
Number of Set Screws
2
Maximum Bore Diameter
0.625 in
Stocked Finished Bore
5/8 in
