Martin 40BS20HT3/4 Saber Finished Bore Sprocket - Bored to Size, 0.7500 in Bore, 20 Teeth

Product Description

The Martin 40BS20HT3/4 is a saber finished bore sprocket with a bore diameter of zero point seven five inches and twenty teeth. It is made of high carbon steel and engineered to precise tolerances. This sprocket is ideal for use in mechanical power transmission systems.

• Finished bore design with two set screws
• Concentric bores to pitch line
• Manufactured to meet ANSI standards

Product Highlights

This sprocket features hardened teeth and is ready for installation on a shaft with keyways.

Product Information

Standard Information

• Brand: Martin
• Country of Origin: United States

Technical Specifications

• Bore Diameter: 0.7500 inches
• Number of Teeth: 20
• Pitch Diameter: 3.1962 inches
• Set Screw Size: 0.250-20 X 0.250 inches
• Hub Diameter: 2-5/8 inches
• Outside Diameter: 3.4570 inches
• Length Through Bore: 1.0000 inches
• Maximum Bore Diameter: 1.875 inches
• Number of Set Screws: 2
