Martin 40BS1913/16 Bored to Size Sprocket - 40 / 1/2 in - 1.1875 in Bore

Product Description

The Martin 40BS1913/16 is a bored to size sprocket designed for standard roller chains. This sprocket features a bore diameter of one point one eight seven five inches with nineteen teeth. It is made of high carbon steel, ensuring strength and durability.

• Manufactured with keyways and setscrews for easy installation.
• Concentric bore to pitch line to minimize run out.
• Tolerances that meet or exceed ANSI standards.

Product Highlights

This sprocket is suitable for various mechanical power transmission applications, enhancing equipment efficiency and reliability.

Product Information

Standard Information

• Brand: Martin
• Country of Origin: United States

Technical Specifications

• MPN: 40BS1913/16
• Pitch Type: Single
• Tooth Width: 0.284 inches
• Hub Diameter: 2.5 inches
• Bore Diameter: 1.1875 inches
• Pitch Diameter: 3.0378 inches
• Outside Diameter: 3.2960 inches
• Length Through Bore: 1.0000 inches
• Number of Teeth: 19
• Surface Treatment: Protective Coating
• Chain / Sprocket Type: Standard Roller Chain
• Storage Dimensions: 3.6250 inches (Width) x 1.0625 inches (Height) x 3.6250 inches (Length)
