Martin 40BS17HT1 SABER Finished Bore Sprocket - Bored to Size, 1.0000 in Bore, 17 Teeth, Steel Material

Product Description

The Martin 40BS17HT1 is a finished bore sprocket designed for mechanical power transmission. It features a one-inch bore and seventeen teeth, made from high carbon steel. The sprocket comes with a hub diameter of two and one-eighth inches and is suitable for chains with a half-inch pitch. It is ideal for applications where reliable power transfer is needed.

• Constructed from hardened high carbon steel
• Concentric bores minimize run out
• Includes keyways and two setscrews for secure attachment

Product Highlights

This sprocket is specifically designed for durability and precision in mechanical applications.

Product Information

Standard Information

• Brand: Martin
• Country Of Origin: United States

Technical Specifications

• MPN: 40BS17HT1
• Tooth Width: 0.2840 inches
• Bore Diameter: 1.0000 inches
• Hub Diameter: 2-1/8 inches
• Pitch Diameter: 2.7211 inches
• Outside Diameter: 2.9750 inches
• Number Of Hubs: 1
• Number Of Teeth: 17
• Set Screw Size: .313-18 X .313 inches
• Chain Number & Pitch: 40 / 1/2 inches
• Storage Dimension Width: 3.2500 inches
• Storage Dimension Height: 1.0625 inches
• Storage Dimension Length: 3.2500 inches
