Martin 40BS16HT13/16 SABER Finished Bore Sprocket - Bored to Size, 1.1875 in Bore, 16 Teeth

Product Description

The Martin 40BS16HT13/16 is a finished bore sprocket designed for mechanical power transmission. This sprocket features a bore size of one point one eight seven five inches and has sixteen teeth. It is constructed from high carbon steel, ensuring durability and reliability in various applications.

• Finished bore sprockets available with hardened teeth
• Precise machining ensures high-quality performance
• Keyways and setscrews included for secure installation

Product Highlights

These sprockets are ideal for transmission systems, offering compatibility with chain number 40 and a pitch of one-half inch.

Product Information

Standard Information

• Brand: Martin
• Country of Origin: United States

Technical Specifications

• Bore Diameter: 1.1875 inches
• Number of Teeth: 16
• Hub Diameter: 2 inches
• Outside Diameter: 2.8140 inches
• Set Screw Size: .313-18 X .313 inches
• Maximum Bore Diameter: 1.375 inches
• Length Through Bore: 0.8750 inches
• Pitch Diameter: 2.5629 inches
• Storage Dimension Width: 2.8750 inches
• Storage Dimension Height: 0.9375 inches
