Martin 36H300SK Reborable Timing Pulley

Product Description

The Martin 36H300SK is a reborable timing pulley designed for precision and reliability. It features evenly spaced grooves for effective engagement with timing belts, minimizing friction during operation.

• Constructed from cast iron for durability
• Designed for a belt pitch of 0.5 inches and a width of 3 inches
• Operates with a minimal backlash for enhanced performance

Product Highlights

This timing pulley excels in various applications such as mixers, conveyors, and paper machinery due to its robust design and reliable performance.

Product Information

Standard Information

• Brand: Martin
• MPN: 36H300SK

Technical Specifications

• Belt Size: H
• Bushing Type: Quick Disconnect
• Hub Type: A
• Bore Range [Max]: 2.625 inches
• Outside Diameter: 5.678 inches
• Bore Type: Bushed
• Bore Range [Min]: 0.5 inches
• Belt Pitch: 0.5 inches
• No. of Teeth: 36
• Pitch Diameter: 5.73 inches
• Length Through Bore: 3.375 inches
• Material: Cast Iron
• Bushing Series: SK
• Belt Width: 3 inches
• Hardened Teeth: With Hardened Teeth
• Weight: 11.1 LB
• EAN or UPC: 697950152103
