Martin 36H200SK Reborable Timing Pulley 0.5 in Pitch 2 in Belt Width SK

Product Description

The Martin 36H200SK is a reborable timing pulley designed for precise timing belt applications. This pulley features evenly spaced grooves, ensuring proper engagement with the belt teeth while minimizing friction. It is suitable for a variety of applications, including agitators, compressors, and conveyors.

• 0.5 inch belt pitch
• 2 inch belt width
• 36 teeth

Product Highlights

This timing pulley is lightweight and requires no lubrication. Its compact design enhances performance while allowing for quick disconnect bushing types.

Product Information

Standard Information

• Brand: Martin
• MPN: 36H200SK

Technical Specifications

• Belt Width: 2 inches
• Bore Range [Min]: 0.5 inches
• No. of Teeth: 36
• Hub Type: A
• Pitch Diameter: 5.73 inches
• Bore Range [Max]: 2.625 inches
• Bore Type: Bushed
• Bushing Series: SK
• Outside Diameter: 5.678 inches
• Material: Cast Iron
• Weight: 8.0 LB
• EAN or UPC: 697950152097
