Martin 35BS205/8 Sprocket 5/8 in Dia Bore 20 Teeth #35 Chain

Product Description

The Martin 35BS205/8 is a bored-to-size type BS single pitch roller chain sprocket designed for efficient power transmission. This sprocket features a five eighths inch bore diameter and is compatible with #35 chains. It has a total of twenty teeth and measures two point five nine three inches in outside diameter.

• Made from durable steel for long-lasting use.
• Includes keyway for secure installation.
• Designed with precision for minimal run out.

Product Highlights

This sprocket is built to last, allowing for dependable operation in chain drive systems.

Product Information

Standard Information

• Manufacturer: Martin Sprocket & Gear
• Type: Bored-to-Size Type BS

Technical Specifications

• Bore Diameter: five eighths inch
• Chain Size: #35
• Hub Diameter: one point nine three eight inches
• Keyway Size: three sixteenth by three thirty-second inch
• Length Through Bore: three fourths inch
• Material: Steel
• Number of Teeth: twenty
• Pitch: three eighths inch
• Pitch Diameter: two point three nine seven inches
• Screw Size: one quarter twenty by one fourth inch
