Martin 35BS163/4 Bored to Size Sprocket - 35/3/8 in, Bored to Size, 0.7500 in Bore, 16 Teeth

Product Description

The Martin 35BS163/4 Bored to Size Sprocket is a mechanical component designed for efficient power transmission. It features a standardized roller chain configuration, making it suitable for various applications in machinery and conveyor systems.

• Bored to fit shafts directly with pre-drilled sizes
• Constructed from high carbon steel for durability
• In stock and ready for immediate shipment

Product Highlights

This sprocket has sixteen teeth, a bore diameter of zero point seven five inches, and is designed to meet ANSI standards for quality and consistency.

Product Information

Standard Information

• Brand: Martin
• Part Number: 00167268

Technical Specifications

• Tooth Width: 0.168 in
• Hub Diameter: 1.4688 in
• Bore Diameter: 0.7500 in
• Pitch Diameter: 1.9222 in
• Outside Diameter: 2.1100 in
• Chain Number & Pitch: 35 / 3/8 in
• Surface Treatment: Protective Coating
• Number Of Teeth: 16
• Length Through Bore: 0.7500 in
• Storage Dimension Width: 2.3125 in
• Storage Dimension Height: 0.8125 in
• Storage Dimension Length: 2.3125 in
