Martin 302017/8 Taper Lock Bushing - 1.8750 in Bore - 1/2 x 1/4 in Keyway

Product Description

The Martin Taper Lock Bushing 302017/8 is designed for use in various mechanical power transmission applications. This bushing features a bore diameter of one point eight seven five inches and a keyway size of one half by one quarter inches. It provides secure clamping on shafts and is ideal for use with sprockets, sheaves, and pulleys.

• Made from durable steel material
• Utilizes tapered design for enhanced clamping force
• Easy to install with screws for secure attachment

Product Highlights

Use the Martin Taper Lock Bushing for reliable performance in industrial settings. Its design offers convenience and improved strength over traditional bushings.

Product Information

Standard Information

• Country Of Origin: United States
• Min Order Qty: 1

Technical Specifications

• Bore Diameter: 1.8750 inches
• Outside Diameter: 4-1/4 inches
• Length Through Bore: 2 inches
• Screw Length: 1-1/4 inches
• Wrench Torque: 800 in/lb
• Bolt Circle Diameter: 4 inches
• Number Of Bolt Holes: 2
• Max Hub Outside Diameter: 5-5/8 inches, 6-1/4 inches, 7 inches
