Martin 24L050SH L Series, 3/8 Pitch QD Timing Pulley

Product Description

The Martin 24L050SH L Series, 3/8 Pitch QD Timing Pulley is designed for precision and efficiency in mechanical power transmission systems. This timing pulley features well-defined grooves that promote accurate engagement with belt teeth, ensuring minimal friction during operation.

• Bore range options from one half inch to one and five eighths inches
• Lightweight steel design with hardened teeth
• Designed for easy installation with quick disconnect bushing

Product Highlights

Ideal for various applications including agitators, conveyors, and compressors, providing consistent speed with minimal backlash.

Product Information

Standard Information

• Brand: Martin
• MPN: 24L050SH

Technical Specifications

• No. of Teeth: 24
• Bore Range [Min]: 1/2 inch
• Outside Diameter: 2.837 inches
• Bushing Series: SH
• Hub Type: A
• Material: Steel
• Length Through Bore: 0.752 inches
• Belt Size: L
• Bore Range [Max]: 1 5/8 inches
• Pitch Diameter: 2.865 inches
• Bore Type: Bushed
• Belt Pitch: 3/8 inch
• Belt Width: 1/2 inch
• Hardened Teeth: With Hardened Teeth
• Weight: 0.69 pounds
• EAN or UPC: 697950151588
