Martin 24H150SD H Series, 1/2 Pitch QD Bushed Timing Pulley

Product Description

The Martin 24H150SD is a timing pulley designed for efficient, positive engagement with belts. It features axial grooves that facilitate smooth operation with reduced friction. This pulley is available in a variety of widths and diameters to fit different applications.

• Functionality: Ensures effective power transmission with minimal wear.
• Applications: Suitable for use in agitators, conveyors, compressors, and pumps.
• Design: Equipped with SD bushing for adaptability in bore sizes.

Product Highlights

Engineered to ensure constant speed without slipping, the timing pulley emphasizes high strength and a compact design for space-saving installation.

Product Information

Standard Information

• Brand: Martin
• MPN: 24H150SD

Technical Specifications

• Pitch Diameter: 3.820 inches
• Bushing Type: QD
• Type: EF-1
• Bore Type: Taper-Lock and QD Bushed
• Bore Range [Max]: 2 inches
• Outside Diameter: 3.766 inches
• Belt Size: H
• No. of Teeth: 24
• Belt Width: 1.5 inches
• Bushing Series: SD
• Bore Range [Min]: 0.5 inches
• Belt Pitch: 0.5 inches
• Weight: 2.6 lbs
• EAN or UPC: 697950151533
