Martin 20H100SH H Series, 1/2 Pitch QD Bushed Timing Pulley

Product Description

The Martin 20H100SH is a H Series, 1/2 pitch QD bushed timing pulley. It features evenly spaced axial grooves for positive engagement with belt teeth, minimizing friction during operation.

• Lightweight design for ease of installation.
• No lubrication is required, promoting maintenance-free operation.
• Compatible with various applications including conveyors and pumps.

Product Highlights

This timing pulley is suitable for high torque applications and provides non-slip performance.

Product Information

Standard Information

• Brand: Martin
• MPN: 20H100SH

Technical Specifications

• Outside Diameter: 3.1290 inches
• Belt Pitch: 1/2 inches
• Belt Width: 1 inch
• No. of Teeth: 20
• Pitch Diameter: 3.183 inches
• Bore Range (Min): 1/2 inches
• Bore Range (Max): 1 5/8 inches
• Bushing Type: QD
• Bushing Series: SH
• Weight: 1.2 LB
