Martin 20122 2012 2 MSG Standard Taper Lock Bushing 2 in Dia Bore 2012 2

Product Description

Martin 20122 is a standard taper lock bushing used in various applications. It features a bore diameter of two inches, making it suitable for many drive solutions.

• Bore Diameter: 2 inches
• Material: Steel
• Torque Rating: 7150 in-lb

Product Highlights

This bushing is designed for flush mounting and ensures easy alignment with minimal space. It meets the ANSI B15.1 standards, making it reliable for demanding environments.

Product Information

Standard Information

• Brand: Martin Sprocket & Gear
• Manufacturer Part Number: 20122

Technical Specifications

• Barrel Diameter: 2-3/4 inches
• Hub Diameter: 3-7/8 inches
• Total Length: 1-1/4 inches
• Screw Size: 7/16 x 7/8 inches
• Keyway Size: 1/2 x 3/16 inches
• Taper: 8 degrees
• Number of Bolt Holes: 2
• Bolt Circle Diameter: 2-5/8 inches
• Torque Rating: 7150 in-lb
• Country of Origin: US
• Type: Standard
