Martin 1VP563/4 Variable Pitch Sheave - 1 Groove, 3L, A, 4L, B, 5L Belt Section Size

Product Description

The Martin 1VP563/4 is a variable pitch sheave designed for various belt section sizes, including 3L, A, 4L, B, and 5L. It features a bore diameter of zero point seven five inches and an outside diameter of five point three five inches, making it suitable for numerous applications in mechanical power transmission.

• Stationary adjustable speed sheaves
• Positive locking system for secure operation
• Precise machining for consistent finish and quality

Product Highlights

This product is a reliable choice for those in need of variable pitch pulleys in industrial settings.

Product Information

Standard Information

• Brand: Martin
• Country of Origin: Mexico

Technical Specifications

• Weight: 4.08 lbs
• Material: Cast Iron
• Bore Type: Finished
• Keyway Size: 3/16 x 3/32 inches
• Sheave Type: VP
• Bore Diameter: 0.7500 inches
• Number of Grooves: 1
• Length Through Bore: A 1 15/16, B 2 5/32 inches
• Hub Outside Diameter: 2.5000 inches
• Storage Dimension Width: 6 inches
• Storage Dimension Height: 2.3 inches
• Storage Dimension Length: 6 inches
