Martin 16CH2206 Screw Conveyor Hangers - Style 220 (Each)

Product Description

Martin produces the 16CH2206 Screw Conveyor Hangers, designed specifically for 16-inch diameter screw configurations. These hangers are ideal for mounting on the tops of trough flanges, providing secure support without obstructing material flow. The design is not intended for environments requiring dust-tight or weatherproof conditions. The hangers come equipped with friction-type bearings for additional durability.

• Hanger Type: Style 220
• Compatible Conveyor Diameter: 16 inches
• Oil Pipe: Not included

Product Highlights

The 16CH2206 is suitable for high-capacity conveyors and offers reliable support while allowing free flow of materials.

Product Information

Standard Information

• Part Number: 100847470
• Brand: Martin
• Availability: In Stock

Technical Specifications

• Hanger Type: 220
• Bolt Hole Width: 19 3/4 inches
• Mounting Distance (Drop): 11 1/8 inches
• Coupling O.D.: 3 inches
• Bolt Hole Length: 2 1/2 inches
• Weight: 33.0 lb
• EAN or UPC: 697950099934
