Martin 16101 Taper Lock Bushing - 1610 Series, 1.0000 in Bore, 1/4 x 1/8 in Keyway

Product Description

The Martin 16101 Taper Lock Bushing is designed for effective power transmission with a bore size of one inch. This bushing features a unique tapered design that enables secure clamping on a shaft. It is made from durable steel material and includes a quarter by an eighth inch keyway, ensuring a strong connection.

• Utilizes screws to tighten securely on the shaft
• Ideal for use on sprockets, sheaves, and pulleys
• Compact design enhances performance over standard bushings

Product Highlights

This Taper Lock Bushing helps in achieving increased clamping force and provides a robust locking mechanism.

Product Information

Standard Information

• Brand: Martin
• Country of Origin: United States

Technical Specifications

• MPN: 16101
• Bore Diameter: 1.0000 in
• Outside Diameter: 2-1/4 in
• Length Through Bore: 1 in
• Screw Length: 5/8 in
• Wrench Torque: 175 in/lb
• Max Hub Outside Diameter: 4 in, 3-1/4 in, 3-5/8 in
• Number of Bolt Holes: 2
• Bolt Circle Diameter: 2-1/8 in
