Martin 10S 1 7/16 | QUADRA-FLEX Coupling Flange

Product Description

The Martin 10S 1 7/16 is a QUADRA-FLEX coupling flange designed for standard shaft applications. This coupling is made from high strength cast iron, making it a reliable choice for various mechanical power transmission tasks.

• Flanges are bored to fit any standard shaft size.
• Produced from durable cast iron material.
• Easy installation and removal process.

Product Highlights

This coupling flange is suitable for a variety of mechanical applications and can handle maximum speeds up to 3,600 RPM.

Product Information

Standard Information

• Brand: Martin
• Part Number: 10S 1 7/16

Technical Specifications

• Hub Material: Cast Iron
• Bore Size: 1.4375 inches - 1 7/16 inches
• Length Through Bore: 2.913 inches
• Weight: 10.5 lb
• Max RPM: 3,600 rpm
• Lock Type: Setscrew
• Hub Dia.: 4 3/8 inches
• Outside Dia.: 7 1/2 inches
