Martin 100E27H Saber Tooth Bushing Bore Roller Chain Sprocket - QD 100 / 1-1/4 in 27 Teeth E Bushing

Product Description

The Martin 100E27H is a Saber Tooth Bushing Bore Roller Chain Sprocket designed for mechanical power transmission. This sprocket features 27 teeth and is made from steel material, ensuring durability in various applications.

• Hardened teeth for longer chain and sprocket life
• Meets or exceeds ANSI standards for tolerances
• Compatible with QD bushings from other manufacturers

Product Highlights

Designed to enhance the efficiency of roller chain drives, this sprocket is ideal for drives with a high speed and specific drive ratios.

Product Information

Standard Information

• Brand: Martin
• Country of Origin: United States

Technical Specifications

• Weight: 19.00 lbs
• Material: Steel
• Bore Type: Bushed
• Pitch Type: Single
• Bushing Size: E
• Bushing Type: QD Bushing
• Hub Diameter: 6 in
• Number of Teeth: 27
• Outside Diameter: 11.4440 in
• Pitch Diameter: 11.1643 in
• Overall Width: 2-15/16 in
• Length Through Bore: 1.6250 in
• Surface Treatment: Protective Coating
