Martin 100BTB36 Bushing Bore Roller Chain Sprocket - Taper Locking, 100 / 1-1/4 in, 36 Teeth, 3020 Bushing, Steel Material

Product Description

The Martin 100BTB36 is a taper locking bushing bore roller chain sprocket designed for precision and reliability. It features a bore size of one and one-fourth inches and has thirty-six teeth, making it suitable for a variety of mechanical power transmission applications. This sprocket is manufactured in the United States from high carbon steel.

• High precision machining to meet ANSI standards.
• Easy installation with a tapered bushing that provides a tight fit on the shaft.
• Compatible with standard roller chains.

Product Highlights

Manufactured with a protective coating, this sprocket ensures longevity and durability in tough environments.

Product Information

Standard Information

• Brand: Martin
• Country Of Origin: United States

Technical Specifications

• Pitch Type: Single
• Number Of Teeth: 36
• Pitch Diameter: 14.3421 in
• Hub Diameter: 5-1/4 in
• Length Through Bore: 2.0000 in
• Chain Number & Pitch: 100 / 1-1/4 in
• Overall Width: 2 in
• Outside Diameter: 15.0380 in
