Product Description
The Martin 100BS16115/16 is a bored to size sprocket designed for various mechanical power transmission applications. This sprocket features a one point nine three seven five inch bore and sixteen teeth, making it suitable for standard roller chain types. It is made from steel, ensuring durability and effectiveness in operation.
- Includes keyways and setscrews for easy installation.
- Manufactured to meet ANSI standards for precision.
- Protective coating enhances longevity.
Product Highlights
This sprocket is shaft ready, is keyed on centerline of tooth, and meets specific manufacturing tolerances.
Product Information
Standard Information
-
Brand: Martin
-
Country of Origin: United States
Technical Specifications
-
Weight: 9.20 lbs
-
Material: Steel
-
Bore Type: Bored to Size
-
Pitch Type: Single
-
Keyway Size: 1/2 x 1/4 in
-
Tooth Width: 0.692 in
-
Hub Diameter: 4-1/2 in
-
Bore Diameter: 1.9375 in
-
Number of Teeth: 16
-
Outside Diameter: 7.0340 in
-
Length Through Bore: 1.7500 in
-
Chain Number & Pitch: 100 / 1-1/4 in
-
Chain / Sprocket Type: Standard Roller Chain
-
Pitch Diameter: 6.4073 in
-
Storage Dimension Width: 7.0340 in
-
Storage Dimension Height: 1.75 in
-
Storage Dimension Length: 7.0340 in
