Marsh Bellofram X32509P 4 0-200 PSI 1/4 Lm Liquid Filled Pressure Gauge

Product Description

The MARSH BELLOFRAM X32509P severe service liquid filled gauge is designed for rugged and harsh environments, especially where pulsation or vibration is present. The liquid filling provides cushioning and dampening, reducing pointer flutter and lubricating the internals. It features a 4 IN dial and measures from 0 to 200 PSI, with a 1/4 IN NPT lower connection.

• Designed to perform in rugged and harsh environmental conditions
• Cushioning and dampening effect
• Reduces pointer flutter

Product Highlights

This liquid filled pressure gauge is ideal for applications needing accurate pressure readings in demanding conditions. Its stainless steel case and polycarbonate lens ensure durability.

Product Information

Standard Information

• Brand: MARSH BELLOFRAM
• Manufacturer Part Number: X32509P

Technical Specifications

• Dial Size: 4 IN
• Measuring Range: 0 - 200 PSI
• Units Of Measure: PSI, KPA
• Connection: 1/4 IN NPT Lower
• Accuracy: Plus/Minus 2-1-2% (ASME Grade A)
• Dial Face: Black Markings On White
• Case Material: 304 Stainless Steel
• Lens Material: Polycarbonate
• Pointer Material: Black Aluminum
• Movement Material: Brass
• Tube Material: Copper Alloy
• Socket Material: Copper Alloy
• Filled With: Glycerin
• Length: 3.89 IN
• Width: 3.89 IN
