Marsh Bellofram P0148 Process Gauge 0-100 PSI 4-1/2

Product Description

The MARSH BELLOFRAM P0148 is a process gauge with over 125 years of proven performance. This turret-style pressure gauge features SAFECASE solid-front construction and a 4-1/2 IN dial. It measures pressure ranging from 0 to 100 PSI with an accuracy of Plus/Minus 0.5% full scale.

• Turret Style Process Pressure Gauge
• SAFECASE solid-front construction
• Black markings on white dial face

Product Highlights

The Marsh Bellofram P0148 gauge is an intelligent and practical choice for process instrumentation.

Product Information

Standard Information

• Brand: MARSH BELLOFRAM
• Manufacturer Part Number: P0148

Technical Specifications

• Dial Size: 4-1/2 IN
• Measuring Range: 0 - 100 PSI
• Units Of Measure: PSI
• Connection: 1/4 IN NPT Lower
• Accuracy: Plus/Minus 0.5% Full Scale (ASME Grade 2A)
• Graduations: 1 Smallest, 10 Largest
• Dial Face: Black Markings On White
• Case Material: Polypropylene
• Lens Material: Acrylic
• Pointer Material: Black Aluminum
• Movement Material: Stainless Steel
• Tube Material: Copper Alloy
• Socket Material: Copper Alloy
• Length: 5.85 IN
• Width: 5.85 IN
• Depth: 3.13 IN
• Brand: Marsh
• MPN: P0148
• Model: P0148
• Type: Turret Style
