Marsh Bellofram P0140 Process Gauge 0-15 PSI 4-1/2

Product Description

The MARSH BELLOFRAM P0140 process gauge offers reliable performance with over 125 years of proven experience. This turret style process pressure gauge features a 4-1/2 IN dial and measures pressure ranging from 0 to 15 PSI. It has a 1/4 IN NPT lower connection and accuracy of Plus/Minus 0.5% full scale.

• Turret Style Process Pressure Gauge
• SAFECASE solid-front construction
• Accuracy: Plus/Minus 0.5% Full Scale (ASME Grade 2A)

Product Highlights

Features SAFECASE solid-front construction, black markings on white dial face, and stainless steel movement.

Product Information

Standard Information

• Brand: MARSH BELLOFRAM
• Manufacturer Part Number: P0140
• Country of Origin: US

Technical Specifications

• Dial Size: 4-1/2 IN
• Measuring Range: 0 - 15 PSI
• Units Of Measure: PSI
• Connection: 1/4 IN NPT Lower
• Accuracy: Plus/Minus 0.5% Full Scale (ASME Grade 2A)
• Graduations: 0.1 Smallest, 1 Largest
• Dial Face: Black Markings On White
• Case Material: Polypropylene
• Lens Material: Acrylic
• Pointer Material: Black Aluminum
• Movement Material: Stainless Steel
• Tube Material: Copper Alloy
• Socket Material: Copper Alloy
• Length: 5.85 IN
• Width: 5.85 IN
• Depth: 3.13 IN
• Type: Turret Style
• MPN: P0140
• Brand: MARSH INSTRUMENTS
