Marsh Bellofram L31106 3 50-300 Bi-Metal Thermometer 2-1/2 Back Stem

Product Description

The MARSH BELLOFRAM L31106 bi-metal thermometer is a heavy-duty instrument for temperature indication in dual scale ranges from -50 to 1000 DEG F (-40 to 525 DEG C). The hermetically sealed case is resistant to shock, vibration, dust, and moisture. It features an external adjustment screw on the back for convenient reset and field calibration. Built-in over-range protection is a standard feature.

• Easy-to-read dual scale
• Fast response
• Accurate temperature indication
• Hermetically sealed case resistant to shock, vibration, dust, and moisture

Product Highlights

This thermometer has a bi-metal sensing element that provides accuracy to within 1% of scale. It is suitable for temperature monitoring in various industrial applications.

Product Information

Standard Information

• Brand: MARSH BELLOFRAM
• Manufacturer Part Number: L31106

Technical Specifications

• Dial Size: 3 IN
• Temperature Rating: 50 - 300 DEG F And 10 - 150 DEG C
• Connection Type: 1/2 IN NPT
• Connection Location: Center Back
• Sensing Element: Bi-Metal
• Stem Size: 2-1/2 IN Length X 1/4 IN Diameter
• Accuracy: 1% Full Scale Of Span Throughout Entire Range For 2 IN Immersion In Liquids, 4 IN In Gases
• Case Material: 304 Stainless Steel
• Stem Material: Stainless Steel
• Window: Glass
• Item Name: Bi-Metal Thermometer
• Part #: L31106
