Marsh Bellofram L31104 Bi-Metal Thermometer 0-200F 2-1/2 Back Stem

Product Description

The MARSH BELLOFRAM L31104 bi-metal thermometer is a heavy-duty instrument designed for temperature indication in dual scale ranges from -50 to 1000 DEG F (-40 to 525 DEG C). The Series "L" thermometer features an easy-to-read dual scale, fast response, and accurate temperature indication. Its hermetically sealed case resists shock, vibration, dust, and moisture.

• Features an easy-to-read dual scale and fast response.
• Provides accurate temperature indication with a bi-metal sensing element.
• Includes an external adjustment screw for convenient reset and field calibration.

Product Highlights

This bi-metal thermometer has a 3 IN dial, a temperature rating of 0 - 200 DEG F And -20 To 90 DEG C, and a 1/2 IN NPT connection.

Product Information

Standard Information

• Brand: MARSH BELLOFRAM
• Manufacturer Part Number: L31104
• Country of Origin: United States

Technical Specifications

• Dial Size: 3 IN
• Temperature Rating: 0 - 200 DEG F And -20 To 90 DEG C
• Connection Type: 1/2 IN NPT
• Connection Location: Center Back
• Sensing Element: Bi-Metal
• Stem Size: 2-1/2 IN Length X 1/4 IN Diameter
• Accuracy: 1% Full Scale Of Span Throughout Entire Range For 2 IN Immersion In Liquids, 4 IN In Gases
• Outside Diameter: 3.28 IN
• Case Material: 304 Stainless Steel
• Stem Material: Stainless Steel
• Window: Glass
• Depth: 3/4 IN
• Item Name: Bi-Metal Thermometer
• MPN: L31104
• Brand: MARSH INSTRUMENTS
• Category: Controls & Indicators
• Subcategory: Thermometer
