Marsh Bellofram J9064 4-1/2 0-600 PSI Pressure Gauge 1/4 LM

Product Description

The MARSH BELLOFRAM J9064 general service steel case gauge is designed for reliable pressure measurements. It is suitable for use with water, oil, air, gas or other noncorrosive media from vacuum/compound through 5000 PSI. The gauge features black markings on a white dial face.

• Cost-effective
• General purpose instrument
• Reliable pressure measurements

Product Highlights

This gauge is designed for pressure measurement with noncorrosive media. It features a black steel case and a flat glass lens.

Product Information

Standard Information

• Brand: MARSH BELLOFRAM
• Manufacturer Part Number: J9064

Technical Specifications

• Dial Size: 4-1/2 IN
• Measuring Range: 0 - 600 PSI
• Units Of Measure: PSI, KPA
• Connection: 1/4 IN NPT Lower
• Accuracy: Plus/Minus 3-2-3% (ASME Grade B)
• Graduations: 10 Smallest, 50 Largest
• Dial Face: Black Markings On White
• Case Material: Black Steel
• Lens Material: Flat Glass
• Pointer Material: Black Aluminum
• Movement Material: Brass
• Tube Material: Copper Alloy
• Socket Material: Copper Alloy
• Length: 4.53 IN
• Width: 4.53 IN
• Depth: 1.22 IN
• Filled With: Dry
