Marsh Bellofram J9040 Pressure Gauge 4-1/2 0-15 PSI 1/4 LM

Product Description

The MARSH BELLOFRAM J9040 general service steel case gauge is designed for reliable pressure measurements. Suitable for use with water, oil, air, gas or other noncorrosive media from vacuum/compound through 5000 PSI. It has a 4-1/2 IN dial and measures from 0 - 15 PSI.

• Cost-effective
• General purpose instrument
• Reliable pressure measurements

Product Highlights

This gauge is designed for pressure measurement of noncorrosive media with a black steel case and a 4-1/2 IN dial.

Product Information

Standard Information

• Brand: MARSH BELLOFRAM
• Manufacturer Part Number: J9040

Technical Specifications

• Dial Size: 4-1/2 IN
• Measuring Range: 0 - 15 PSI
• Units Of Measure: PSI, KPA
• Connection: 1/4 IN NPT Lower
• Accuracy: Plus/Minus 3-2-3% (ASME Grade B)
• Graduations: 0.2 Smallest, 3 Largest
• Dial Face: Black Markings On White
• Case Material: Black Steel
• Lens Material: Flat Glass
• Pointer Material: Black Aluminum
• Movement Material: Brass
• Tube Material: Copper Alloy
• Socket Material: Copper Alloy
• Length: 4.53 IN
• Width: 4.53 IN
• Depth: 1.22 IN
• Filled With: Dry
• Part #: J9040
