Marsh Bellofram J7654P Pressure Gauge 0-200 PSI 2-1/2

Product Description

The MARSH BELLOFRAM J7654P pressure gauge is designed for rugged and harsh environmental conditions, especially where pulsation or vibration is present. This severe service liquid filled gauge features a 2-1/2 IN dial and measures from 0 to 200 PSI. It has black markings on a white dial face and a 1/4 IN NPT lower connection.

• Designed for rugged and harsh environmental conditions
• Suitable for applications with pulsation or vibration
• Liquid filled for cushioning and dampening

Product Highlights

This gauge reduces pointer flutter and lubricates internals, ensuring accurate and reliable pressure measurements.

Product Information

Standard Information

• Brand: MARSH BELLOFRAM
• Manufacturer Part Number: J7654P
• Country of Origin: China

Technical Specifications

• Dial Size: 2-1/2 IN
• Measuring Range: 0 - 200 PSI
• Units Of Measure: PSI, KPA
• Connection: 1/4 IN NPT Lower
• Accuracy: Plus/Minus 3-2-3% (ASME Grade B)
• Dial Face: Black Markings On White
• Case Material: 304SS
• Lens: Polycarbonate
• Pointer Material: Black Aluminum
• Movement: Brass
• Tube Material: Copper Alloy
• Socket Material: Copper Alloy
• Filling: Glycerin Filled
• Length: 2.68 IN
• Width: 2.68 IN
• Manufacturer: MARSH
• Series: Severe Service Series
• Model: J7654P
• Primary Range: 0-200 psi
• Secondary Scale: kPa
• Gauge Type: Pressure
• Connection Location: Bottom
• Connection Size: 1/4" NPT
• Lens Type: Polycarbonate
• Dry or Filled: Glycerin
• Wetted Parts: Copper
• Brand: Marsh Bellofram
• MFG Part#: J7654P
• Part #: J7654P
• Category: Pneumatics
• Subcategory: Pneumatic Gauge
